Discovery of Freshly Created
Martian Stain Features

March 18, 2001

Jill@eskimo.com (Jill England)


Efrain Palermo's Web Site dedicated to Martian Flow features.

Zip file of this web page and images for re-posting or local offline viewing.

Discovery!

For almost a year, there has been a debate about the so-called flow or stain images on the surface of Mars. The intriguing possibility is that they are flows of water from sources beneath the surface happening as real water runoff today.

If the hypothesis that stains represent current water flow features is true, then it should be possible to see new ones form and old stains change and disappear.

If on the other hand stains can be shown to be persistent and unchanging then they are presumably longer lived features and there is no current activity to generate them.

Method

The method used in this image analysis will be to find overlapping images, if any, in the list of images of stains collected to date. Images found will have a time lapse and stain features can then be compared.

To identify images that are close to each other and possibly overlap a "Great Circle Distance" is calculated for every combination of images in the known stain image list.

When overlapping images are found they will need to have comparable resolutions and be of high enough resolution to discern surface features clearly.

Qualifying images can be compared to identify any stain feature changes such as new stains being created or old stains becoming invisible. Measurements of any such features should be calculated by multiplying the pixel resolution by the length (in pixels) of the artifact on the image. Note that distances calculated this way will only be estimates due to various combinations of hills and camera angles.

As a final part of the analysis a red/blue stereo picture should be created if possible.

Results

The list of images used in this comparison have already been identified to contain stain features. A copy of this image list may be found here.

Image List used for these distance tests

The distances between each image and all the rest in the list above were calculated generating a report of over 6000 combinations. The top 100 closest matches are listed here.

Closest 100 images

Two overlapping images containing stains, FHA/01100 and M04/01228 have been identified. These two images were taken on March 19, 1999 and August 16, 1999 respectively. The images were taken 5 months apart. It is not believed that the seasons at this latitude change the climate substantially.
Image Name Image Time Resolution
meters/pixel
Center
Latitude
Center
Longitude
Martian Season
FHA/01100 March 19, 1999 1.44 -8.34 155.05 Early winter
M04/01228 August 16, 1999 4.29 -8.30 155.05 Early spring

Click on image names above to view original images at Malin Space Science Systems.

The images have comparable resolutions of 1.44 meters/pixel and 4.29 meters/pixel. The images are also clear and free from obscuring dust or clouds.

When the images were compared three New stains were discovered in the more recent image that had no counterpart in the older image. None of the older stains has noticeably changed. The three new stains are labeled A, B, and C in these pictures.


Click for full size.

Click for full size.

The lengths of the new stains found in M04/01228 are as follows:

Flow Name Stain LengthApproximate Length in Meters
A11 pixels 45 meters
B20 pixels 84 meters
C32 pixels 139 meters

In comparison to the lengths of these three new stain features, the largest stain features in M04/01228 are approximately 890 meters long.

Conclusions

The following conclusions are drawn;

1. Stains are "Long Lived" surface features that persist for more than 5 months.
2.Stains are very recent surface features forming at the present time on the Martian surface.
3. It seems obvious but it should be pointed out that new stain features appear very dark. Presumably they get lighter over time. Why they start out dark, why they get lighter, and what causes them to suddenly appear are questions that need to be answered.

Future Study

Compare all images in the MOC database searching for other overlapping images containing stain features. This will give additional data and help formulate conclusions about what the stains are made of and how they are forming.

In many other images, faded stain patterns are clearly visible next to darker newer stains. Stain features appear to fade with time. How much time it takes for a stain to fade is a very interesting question and that information could possibly be used to draw conclusions about the creation process and creation rate of the stain features. A possible hypothesis is that stain features will appear in a steady state with old stains fading at the same rate that new stains are being created.

Since stain features are persistent for periods of time longer than Martian seasons it is unlikely that there will be any seasonal correlation between imaging time and seasons. The exercise should still be done however.

Count the number of stains in each image and plot the count against latitude to see if there is a smooth decline in stains as you move away from the equator. Preliminary analysis from Efrain Palermo strongly suggests that this is true.

On the wish list, it would be nice to stand in the middle of a stain and sample it. This would instantly answer many questions.

Acknowledgments

Richard Hoagland

Who just doesn't get enough credit for initiating interest in Space Sciences.

Efrain Palermo

For his Web Site dedicated to Martian Flow features, large list of stain images, and analysis of stain image distributions.

Nasa/JPL/Malin Space Science Systems

 For the images and databases.

USGS-Flagstaff MGS-MOC Web Pages  As an additional archive and access point for the Malin Space Science images and databases.

Special thanks to Nasa/JPL/Malin Space Science Systems for their efforts in organizing and creating this data and most importantly making it's catalog and database available. Thank you so much, exploring Mars and making this discovery, whatever it may mean, has been an exciting and wonderful experience and is the closest I am every likely to get to exploring other worlds.

Thank you!

Disclaimers and Copyright

This paper is neither supported by nor associated with Nasa, JPL, or Malin Space Science Systems.

This paper was not produced for profit nor was any compensation of any sort provided by anyone for this paper's creation or distribution.

This paper is not produced for, supported by, or affiliated with either Richard Hoagland, The Enterprise Mission, or Art Bell.

This paper is Copyright(c) by Jill England, 2001. All rights reserved.
